Dangerous Music BAX EQ Mastering and Mix Bus EQ
Dangerous Music BAX EQ: High-Fidelity Tone Shaping
The Dangerous Music BAX EQ is a mastering-grade equalizer renowned for its smooth tonal control and pristine sound quality. Inspired by the classic Baxandall shelving curves, it provides an unparalleled tool for shaping the overall tonal balance of a mix or master. This unit delivers broad, musical adjustments that add clarity, warmth, or brilliance without sacrificing detail. Ideal for professional mixing and mastering studios, the BAX EQ empowers engineers to refine their tracks with precision and elegance.
Product Features
- Mastering-Grade Shelving EQ: Delivers classic Baxandall-style curves for effortless tonal shaping.
- Pristine Signal Path: Transparent analog circuitry ensures audio integrity without coloration.
- Broad Bandwidth Control: Perfect for adding "air" to high frequencies or tight control over low-end.
- Stepped Controls: Precision adjustments for recallable settings.
- Stereo or Dual-Mono Modes: Flexible for mastering or mixing workflows.
- Bypass Option: True bypass ensures unaltered signal when disengaged.
Functions
- High and Low Shelving: Independently control high and low frequencies for a smooth tonal balance.
- Adjustable Frequency Points: Offers selectable frequency options for more precise tonal sculpting.
- Mastering Precision: Perfect for subtle enhancements or correcting mix imbalances.
- Easy Integration: Designed to fit seamlessly into professional mastering setups.
Product Specifications
| Category | Details |
|---|---|
| Frequency Response | 10 Hz - 40 kHz (+/- 0.1 dB) |
| High Shelf Frequency Points | 18 kHz, 16 kHz, 12 kHz, 8 kHz, 5 kHz |
| Low Shelf Frequency Points | 74 Hz, 65 Hz, 50 Hz, 40 Hz, 28 Hz |
| Gain Range | +/- 5 dB (stepped in 0.5 dB steps) |
| Impedance | Balanced Inputs: 20 kΩ / Outputs: 50 Ω |
| Bypass | True Relay Bypass |
| Connectivity | XLR (Balanced) |
| Power Supply | External PSU (Included) |
| Dimensions | 19” x 1.75” x 10” (1U Rackmount) |
| Weight | 8 lbs (3.63 kg) |
The Dangerous Music BAX EQ is a modern classic, trusted by top-tier engineers for its musicality and precision. Whether you're mastering a hit record or enhancing a mix, this equalizer offers unparalleled control over your sound.
Need help choosing? Talk to Beatbox about compatibility, availability and product warranty.
